SSR-1U Four-Channel Serial Logger with USB
The SSR-1U extends the capabilities of the SSR-1 with USB file access and an additional serial channel. Up to four streams can be logged simultaneously in either raw format (as received) or in a time tagged archive to allow analysis and reconstruction of the serial streams. Start recording automatically at power up, on command through a digital or PWM input, or using software commands. Complete details are provided in the User’s Manual.
Logger Features
- Records four serial channels simultaneously
- USB file access
- Up to 230.4k baud recording on all channels (SR1U22T)
High-speed variant supports 921.6k baud (SR1U22TH) - Two RS232 channels
- Two 3.3V CMOS channels (5V tolerant, 5V TTL compatible)
- Wide supply voltage (4.5 to 32VDC)
- Supports microSD, microSDHC, and microSDXC(>32GB) cards
- Battery backed real time clock
- Raw and time-tagged recording
- Interactive shell for configuration and file system operations
- Flexible record control: digital input, PWM input, software controlled, and automatic
- Flexible recording modes (overwrite/append, user defined path and file names, etc.)
Package Contents
- SSR-1U Serial Data Logger
- Mating connector with 9 inch cable
- Mating connector for USB/Serial channel 4
- Lithium coin cell battery (US Shipments Only)
- A FAT32 formatted MicroSD card with:
- SSR-1U Users Guide,
- puttytel terminal emulator,
- STTP time tagged archive parser
